New energy commercial vehicle
Model |
WH6801BEV1 |
||
Main size parameters | |||
Dimension |
8050×2400×2980 |
||
Wheelbase（mm） |
4100 |
||
|
Tread （mm） |
Front wheel |
1930,1950 |
|
Rear wheel |
1720 |
||
Min.Ground Clearance（Loaded）（mm） |
170 |
||
Front Suspension（mm） |
1825 |
||
Rear Suspension（mm） |
2125 |
||
Approach Angle（°） |
10 |
||
Departure Angle（°） |
9 |
||
Rated passenger |
24-38 |
||
Curb Weight（kg） |
6700 |
||
Max.Weight（kg） |
10000 |
||
Chassis | |||
Tire |
245/70R19.5 |
||
Axle |
Integral F/R axle,Automatic adjustment arm |
||
Suspension Form |
Leaf Spring |
||
Main performance parameters | |||
Min.Turning Diameter（m） |
9 |
||
Max.speed（km/h） |
100 |
||
Recharge mileage（km） |
235 |
||
Battery Type |
Lithium Iron phosphate Battery |
||
Battery Management System |
Intelligent centralized |
||
Total Capacity（kWh） |
92.16 |
||
Charging Time（h） |
2 |
||
Rated Power（kW） |
60 |
||
Motor peak power（kW） |
110 |
||
Motor rated torque（Nm） |
358 |
||
Motor peak torque（Nm） |
1200 |
||
