New energy commercial vehicle
| Model | WH6801BEV1? | |
| Main?size?parameters | ||
| Dimension | 8050×2400×2980 | |
| Wheelbase（mm） | 4100 | |
| Tread（mm） | Front?wheel | 1930,?1950 |
| Rear?wheel | 1720 | |
| Min.Ground?Clearance（Loaded）（mm） | 170 | |
| Front?Suspension（mm） | 1825 | |
| Rear?Suspension（mm） | 2125 | |
| Approach?Angle（°） | 10 | |
| Departure?Angle（°） | 9 | |
| Rated?passenger | 24-38 | |
| Curb?Weight（kg） | 6700 | |
| Max.Weight（kg） | 10000 | |
| Chassis | ||
| Tire | 245/70R19.5 | |
| Axle | Integral?F/R?axle,Automatic?adjustment?arm | |
| Suspension?Form | Leaf?Spring | |
| Main?performance?parameters | ||
| Min.Turning?Diameter（m） | 9 | |
| Max.speed（km/h） | 100 | |
| Recharge?mileage（km） | 235 | |
| Battery?Type | Lithium?Iron?phosphate?Battery | |
| Battery?Management?System | Intelligent?centralized | |
| Total?Capacity（kWh） | 92.16 | |
| Charging?Time（h） | 2 | |
| Rated?Power（kW） | 60 | |
| Motor?peak?power（kW） | 110 | |
| Motor?rated?torque（Nm） | 358 | |
| Motor?peak?torque（Nm） | 1200 | |
